Unique equipment for multiaxial loading: multiaxial testing stand purchased

A new and unique device for multiaxial loading (both quasi-static and dynamic) has been procured for our mechanical testing laboratory. Its main parts are a bed plate and a total of five loading cylinders.

Its capabilities include biaxial loading of cruciform specimens for studies of the effects of anisotropy, testing of the impact of non-linear load paths during multiple-operation deep drawing, and axial-torsion testing. The cylinders capacity is up to 250 kN/2 kNm, at speeds of up to 0.75 m/s. The associated measuring chain can use optical methods, including digital image correlation, offering a vast range of tests on specimens or even entire components.



The new biaxial testing system dedicated for cruciform specimens testing (Biax with load capacity of 50 kN and max. actuator speed 120 mm/min)

Apr 1, 2020

The new biaxial testing machine was designed for COMTES FHT for the biaxial metal sheet deformation experiments and advanced FLC diagrams measurement with the non-linear strain paths. ... more
